汽油机机型 Gasoline engine models |
| 单缸 二冲程 |
水泵类型 |
| 单级离心泵 |
排气量 Exhaust volume |
| ≥134CC |
理论功率 The theoretical maximum power |
| 8HP 7200r/min |
油箱容量 Fuel tank capacity |
| 12L或者24L |
点火系统 The ignition system |
| 无触点晶体管点火Non contact transistor ignition |
启动系统 Starting system |
| 手拉、电启动启动 |
冷却系统 Cooling system |
| 强制风冷 Forced air cooling |
流量 The maximum flow |
| 351 L/min |
额定流量 The rated flow |
| 240 L/min |
扬程 The highest pressure |
| 165米 |
吸程 The maximum suction lift |
| 大于5m |
外型尺寸 Appearance size |
| 380*400*320mm |
进水管口径 The water inlet pipe diameter |
| 50mm |
出水管口径 Outlet pipe diameter |
| 40mm |
整机重量 The weight of the whole machine |
| 14.7kg |
